[giaban]Giá: Liên hệ[/giaban]
[hinhanh]
Nhà sản xuất: GEFRAN
Bảo hành: 12 tháng
[/tomtat]
[kythuat]
| Manufacturer: | Gefran |
| Series: | VDI100 |
| Model: | VDI100-4220-KBX-4-F |
| Application: | general purpose |
| Capacity, kW: | 22 |
| Current, А: | 45 |
| Main power supply, V: | 380-480 |
| Phase: | 3 |
| Output frequency, Hz: | 0,1-599 |
| Enclosure: | IP20 / NEMA 1 |
| Overload capacity, % per 1 min.: | 150 |
| Acceleration time, sec: | 0-6000 |
| Deceleration time, sec: | 0-6000 |
| EMC filter: | EMI filter |
| Braking unit: | Internal braking unit integrated |
| Analog input: | 2 |
| Digital input: | 8 |
| Analog output: | 2 |
| Digital output: | 2 |
| Relay output: | 1 |
| RS485 (Modbus RTU): | RS485 (Modbus, ProfiBus, CANopen, DeviceNet, TCP-IP) |
| PID: | PID control |
| V/f control mode: | + |
| Operation temperature, °С: | -10.....+50 |
| Storage temperature, °С: | -20.....+70 |
| Dimensions (W x H x D), mm: | 265x500x225 |
| Weight, kg: | 12,5 |
VDI100 inverters series offer the utmost flexibility of application to modern automation systems and ensure ease of use, while guaranteeing advanced control capabilities for both asynchronous and permanent magnet SPM and IPM motors.
VDI100 inverter features an intuitive and user friendly interface to enable immediate motor start-up and system functions to implement control architectures for the most advanced application solutions, all with maximum energy efficiency.
The VDI100 series offer a perfect automation system integration with “universal” standard configuration, optional cards and accessories. All these elements offer real advantages in terms of product and system optimization and cost saving.
> Wide motor control capability
> Advanced auto-tuning
> High level sensor vector mode
> Fast computing ability
> Conformity to global standards.
Functions:
- Auto-tuning
- Dual current rating
- Dynamic Braking
- Mechanical brake control
- Simple PLC
- PID control
- Soft-PWM
- Position control
- Speed Search
- Vector control in close loop with encoder
- Application Presets
- MODBUS communication
Options/accessories:
- LCD keypad with internal memory
- PC connection cable (RJ45/USB)
- Braking unit
- Encoder expansion cards
- Fieldbus communication modules (Profibus, Canopen, Devicenet, TCPIP)
- External EMC filters
- Braking resistors
- Chokes
Description
VDI100 - General purpose full vector inverter, from 0.75kW up to 45 kW HD
* Mains supply:
- 3 x 380…480Vac, 50/60Hz
* Motor ratings from 0.75kW (1Hp) to 45kW (60Hp) HD
* Certifications: CE, cULus
Features:
- Motor type: Asynchronous and Synchronous Motor (Surface Permanent Magnet Motor, Interior Permanent Magnet Motor)
- Regulation control modes: V/f, V/f+Encoder, SLV (vector control open loop), SV (vector control closed loop), PMSLV (vector control open loop for Permanent Magnet Motor, PMSV (vector control closed loop for Permanent Magnet Motor)
- Max Output frequency 599Hz
- EMC Filter integrated up to 45kW
- Dynamic Braking Module integrated up to 30kW
- Heavy duty and Light duty overload management
- Multilanguage programming software
- Basic PLC Integrated
- Integrated and removable programming keypad
- 2 Analog inputs: AI1: -10~10V / 0~10V, AI2: 0~10V / 4~20mA
- 2 Analog outputs: AO1:0~10V, AO2:0~10v/4~20mA
- 8 Digital Inputs (PNP / NPN)
- Digital Outputs: 2 (size 1) / 1 (all other sizes)
- Relay Outputs: 1 (size 1) / 2 (all other sizes)
- Others: PTC input (AI2), Pulse input (32kHz), Pulse output (32kHz)
- RS485 Serial Line (Modbus RTU/ASCII protocol)
- Interfacing with the most common fieldbus through communication modules for ProfiBus, CANopen, DeviceNet, TCP-IP
- IP20 / NEMA 1, with standard removable anti dust cover.
